CONFICO 50 – H1 W4 A

TEMPORARY ROAD BARRIER

Road barrier height 50 cm, containment level H1.
The perfect solution for road construction sites with limited space.
Minimal influence on traffic flow.
Loading capacity 144 m.

Download
CONFICO 50 – H1 W4 A
CONFICO 50 – H1 W4 A - Image 2
CONFICO 50 – H1 W4 A - Image 3
CONFICO 50 – H1 W4 A - Image 4
TECHNICAL FEATURES
Barrier
CONFICO 50
Lenght
12 m
Height
50 cm
Base
20 cm
Weight
1860 kg
Anchored barrier
NO
Anchored terminals
YES
CE Certification
YES
CRASH TEST – EN 1317
ASI
A
Containment level
H1
Normalized working width
W4
Dynamic normalized deflection
1.1 m
Normalized vehicle intrusion
VI7
Test length (excluding terminals)
93 m
